Segment Launching Gantry（LG）
Product Description:
Double truss beam bridge girder erection launching gantry crane equipment
The Double truss beam bridge girder erection launching gantry crane equipment is used to construct prefabricated spans up to 60m long. It is designed and fabricated in order to ensure high performances, efficiency, safety, flexibility and multiple successive utilizations.
1. Independent supports relocation system.
2. Independent stressing platform handling system.
3. Service overhead crane.
4. Radio remote controls for all opera tions.
5. Radio remote controlled spreader beam for segment positioning.
product analysis
Basic Construction
1: Low center of gravity, convenient and safe.
2: Convenient installation and wide application range.
3: Accomplish girders with carrying and erection at the same time.
4: SWL Lifting weight: 30 40 50 60 70 80 90 100 120 125 130 150 160 180 200 250 260 300 350 400 450 500 550 600 800 900 1000 1200 1600 tons T.
5:Span:7.5m,10m,15m,20m,24m,25m,30m,32m,35m,40m,45m,50m,55m,60m.
Lifting capacity (t) | 200 | 160 | 120 | 100 | 80 |
| applicable span (m) | ≤55 | ≤50 | ≤40 | ≤35 | ≤30 |
| applicable skew bridge angle | 0-450 | 0-450 | 0-450 | 0-450 | 0-450 |
| trolley lifting speed(m/min) | 0.8 | 0.8 | 0.8 | 1.27 | 0.8 |
| rolley longitudinal moving speed (m/min) | 4.25 | 4.25 | 4.25 | 4.25 | 4.25 |
| cart longitudinal moving speed (m/min) | 4.25 | 4.25 | 4.25 | 4.25 | 4.25 |
| cart transverse moving speed(m/min) | 2.45 | 2.45 | 2.45 | 2.45 | 2.45 |
| transportation capacity (t) | 100X2 | 80 X2 | 60X2 | 50X2 | 50X2 |
| speed of bridge transport vehicle (m/min) | 8.5 | 8.5 | 8.5 | 8.5 | 8.5 |
| return speed (m/min) | 17 | 17 | 17 | 17 | 17 |
And the dimension and capacity all can be customized made as you need, even if you do not know the specific data clearly, pls contact us, our engineer team can suggest a best design and solution for you.
Products Show
Product Delivery
Packaging:
1. Generally, the total net weight of loaded container is 22 tons to 25tons, which need be confirmed before loading.
2. Different packages are used for different products:
---Bundles: Timber beam, steel props, tie rod, etc.
---Pallet: Small parts will be put in bags and then on pallets.
---Wooden cases: It is available on customer's request.
---Bulk: Some irregular goods will be loaded in bulk in container.
Delivery:
1. Production: For full container, normally we need 20-30 days after receive customer's down payment.
2. Transportation: It depends on the destination charge port.
3. Negotiation is needed for special requirements.
